| Place of Origin: | China |
| Brand Name: | leyon |
| Certification: | FM/UL |
| Model Number: | Hot Galvanized Malleable Fittings tee and cross |
| Minimum Order Quantity: | 500piece |
|---|---|
| Price: | Negotiable |
| Packaging Details: | 200piece/carton |
| Delivery Time: | 25-35days |
| Payment Terms: | Western Union, L/C, T/T, D/P, D/A, MoneyGram |
| Supply Ability: | 10000piece/week |
| Specification: | Elbow, Socket, Tee, Union, Bushing, Plug | Item: | 1/8 Inch Hot Galvanized Malleable Fittings Tees |
|---|---|---|---|
| Application: | Steam, Air, Gas And Oil Pipes | Technics: | Sophisticated Metallurgical |
| Technology: | Advanced Metallurgical And Processing | Treaded: | ISO7/1, DIN2999,NPT |
| Size: | 1/8 Inch To 6 Inch | Dimensions: | 19 Mm |
| High Light: | Y Type Galvanized Cross Pipe Fitting,6 Inch Galvanized Cross Pipe Fitting,Malleable Galvanized Cross Pipe Fitting |
||
Pipe Fitting Malleable Iron Black Cross and Y-type Female Tube Threaded Pipe for DIY Furniture Projects
| Material | Malleable iron |
| Standard | Thread: ISO 7/1 |
| Dimension | ISO 49, DIN 2950,EN10242 |
| Chemical property | (C %2.4-2.9), (Si %1.4-1.9), (Mn %0.4-0.65), (P% <0.1), (S% <0.2%) |
| Physical property | Tensile strength>=350Mpa,Elongation>=10% Hardness<=150HB |
| Testing pressure | 2.5Mpa |
| Working pressure | 1.6Mpa |
| Type | Beaded with ribs or banded with ribs |
| Beaded without ribs or banded without ribs | |
| Round/square | |
| Surface | Galvanized/ no galvanized |
| Color | White/black |
| Model | Elbow, Tees, Crosses, Bends, Unions, Bushings, Lateral Braches, Sockets, Nipples, Hexagon/Round, Caps, Plugs, Locknuts, Flanges ,Side Outlet Tees, Side Outlet Elbows and etc |
| Connection | Male, Female |
| Shape | Equal, Reducing |
| Certificate | BSI,ANAB,ISO9001,FM,UL |
| Application | Suitable for pipe connect of steam, air, gas, oil and so on |
| Buyer’s drawings or designs are available | |
| Package | Cartons without pallet |
| Cartons with pallet | |
| Double woven bags | |
| Or as buyer’s requirements | |
|
Delivery details
|
According to the quantities and specifications of each order |
| Normal delivery time is from 30 to 45 days after receiving the deposit |
