Hot Dipped Electric Galvanized Pipe Plug , Plumbing Pipe Plugs Casting Technics

China Hot Dipped Electric Galvanized Pipe Plug , Plumbing Pipe Plugs Casting Technics supplier
Hot Dipped Electric Galvanized Pipe Plug , Plumbing Pipe Plugs Casting Technics supplier Hot Dipped Electric Galvanized Pipe Plug , Plumbing Pipe Plugs Casting Technics supplier Hot Dipped Electric Galvanized Pipe Plug , Plumbing Pipe Plugs Casting Technics supplier

Large Image :  Hot Dipped Electric Galvanized Pipe Plug , Plumbing Pipe Plugs Casting Technics

Product Details:

Place of Origin: China
Brand Name: kanaif
Certification: FM/UL
Model Number: Hot dipped electric Galvanized plug

Payment & Shipping Terms:

Minimum Order Quantity: 100piece
Price: Negotiable
Packaging Details: 200piece/carton
Delivery Time: 25-35days
Payment Terms: L/C, T/T, Western Union, MoneyGram
Supply Ability: 10000piece/week
Contact Now
Detailed Product Description
Color: Galvanized & Black Meterial: Malleable Iron
Technics: Casting Standard: ANSI,BS,DIN
Surface Treatment: Hot Galvanized Head Code: Square
Type: Hot Dipped Electric Galvanized Plug Size: 1/8"-6“

Excel of Hot dipped electric Galvanized plug

Size Inch 1/8 1/4 3/8 1/2 3/4 1 11/4
mm 6 8 10 15 20 25 32
Dim.
(mm)
A 15.5 18.3 20.1 23.9 27.2 31.8 34.5
Size Inch 11/2 2 21/2 3 4 6
mm 40 50 65 80 100 150
Dim.
(mm)
A 36.9 39.7 46 49 64.5 71.5



Top 9 points of Hot dipped electric Galvanized plug

  1. Through airtight test, the quality of every socket can be ensured .


  2. Thread diameter, parallelism, angle, tooth type will be controlled strictly and tested each union with plug gauge.


  3. Avg. thickness of zinc coating is higher than 86 um specified in ASME, EN(70um), DIN(70um), SI(78um).


  4. Smooth surface ,no sand hole on the surface of Hot dipped electric Galvanized plug.


  5. Better toughness and long service life.


  6. Outlet size of Hot dipped electric Galvanized plug is from 1/8”to 6” .


  7. Using high calorific value of natural gas annealing furnace,manipulate the annealing process rigorously,improve the physical properties of the materials.


  8. The cast iron samples are used to test its material’s quality by using spectrometer from Oxford Instruments.


  9. Malleable cast iron pipe elbow processing production using Danish imports of Di sand, Japan's long East and the new East automatic production lines to ensure product quality.



Attached list  of Hot dipped electric Galvanized plug

Material Malleable iron
Standard Thread: ISO 7/1
Dimension ISO 49, DIN 2950,EN10242
Chemical property (C %2.4-2.9), (Si %1.4-1.9), (Mn %0.4-0.65), (P% <0.1), (S% <0.2%)
Physical property Tensile strength>=350Mpa,Elongation>=10% Hardness<=150HB
Testing pressure 2.5Mpa
Working pressure 1.6Mpa
Type Beaded with ribs or banded with ribs
Beaded without ribs or banded without ribs
Round/square
Surface Galvanized/ no galvanized
Color White/black
Model Elbow, Tees, Crosses, Bends, Unions, Bushings, Lateral Braches, Sockets, Nipples, Hexagon/Round, Caps, Plugs, Locknuts, Flanges ,Side Outlet Tees, Side Outlet Elbows and etc
Connection Male, Female
Shape Equal, Reducing
Certificate BSI,ANAB,ISO9001,FM,UL
Application Suitable for pipe connect of steam, air, gas, oil and so on
Buyer’s drawings or designs are available
Package Cartons without pallet
Cartons with pallet
Double woven bags
Or as buyer’s requirements
Delivery details According to the quantities and specifications of each order
Normal delivery time is from 30 to 45 days after receiving the deposit
