Customized Size Plumbing Pipe Fittings , 6 / 4 Inch Pipe Plug Abrasive Resistance

China Customized Size Plumbing Pipe Fittings , 6 / 4 Inch Pipe Plug Abrasive Resistance supplier
Customized Size Plumbing Pipe Fittings , 6 / 4 Inch Pipe Plug Abrasive Resistance supplier Customized Size Plumbing Pipe Fittings , 6 / 4 Inch Pipe Plug Abrasive Resistance supplier Customized Size Plumbing Pipe Fittings , 6 / 4 Inch Pipe Plug Abrasive Resistance supplier

Large Image :  Customized Size Plumbing Pipe Fittings , 6 / 4 Inch Pipe Plug Abrasive Resistance

Product Details:

Place of Origin: China
Brand Name: kanaif
Certification: FM/UL
Model Number: Malleable Iron Pipe Fitting Plug

Payment & Shipping Terms:

Minimum Order Quantity: 100piece
Price: Negotiable
Packaging Details: 200piece/carton
Delivery Time: 25-35days
Payment Terms: L/C, T/T, Western Union, MoneyGram
Supply Ability: 10000piece/week
Contact Now
Detailed Product Description
Color: Galvanized & Black Meterial: Malleable Iron
Technics: Casting Standard: ANSI,BS,DIN
Surface Treatment: Hot Galvanized Head Code: Square
Type: Malleable Iron Pipe Fitting Plug Size: 1/8"-6“

Malleable Iron Pipe Fitting Plugs High pressure Hexagon Plug

Material Malleable iron
Standard Thread: ISO 7/1
Dimension ISO 49, DIN 2950,EN10242
Chemical property (C %2.4-2.9), (Si %1.4-1.9), (Mn %0.4-0.65), (P% <0.1), (S% <0.2%)
Physical property Tensile strength>=350Mpa,Elongation>=10% Hardness<=150HB
Testing pressure 2.5Mpa
Working pressure 1.6Mpa
Type Beaded with ribs or banded with ribs
Beaded without ribs or banded without ribs
Round/square
Surface Galvanized/ no galvanized
Color White/black
Model Elbow, Tees, Crosses, Bends, Unions, Bushings, Lateral Braches, Sockets, Nipples, Hexagon/Round, Caps, Plugs, Locknuts, Flanges ,Side Outlet Tees, Side Outlet Elbows and etc
Connection Male, Female
Shape Equal, Reducing
Certificate BSI,ANAB,ISO9001,FM,UL
Application Suitable for pipe connect of steam, air, gas, oil and so on
Buyer’s drawings or designs are available
Package Cartons without pallet
Cartons with pallet
Double woven bags
Or as buyer’s requirements
Delivery details According to the quantities and specifications of each order
Normal delivery time is from 30 to 45 days after receiving the deposit


Malleable Iron Pipe Fitting Plugs High pressure Hexagon Plug



  • The quality ensuring of Malleable Iron Pipe Fitting Plug is controlled by full automatic product-lines of DISA Denmark ,SINTOKOGIO and DJAMF Japan.

  • The spectrometer of Oxford Instruments we bought for analyzing the quality of Malleable Iron Pipe Fitting Plug samples.

  • In order to improve material physical characteristics ,we set a higher heating value gas furnace to control the annealing process strictly .

  • The size of Malleable Iron Pipe Fitting Plug ranging from 1/8” to 6”.

  • Better toughness creates long using life.

  • No any and hole discovered on surface.Zinc thickness of hot galvanized products, is according to international standard strictly.

  • Thread diameter, parallelism, angle, tooth type have to be finely manufactured , Each union must pass the testing of plug gauge.

  • After tightness test,each socket can be ensured no leakage.



Size excel of Malleable Iron Pipe Fitting Plug

Size Inch 1/8 1/4 3/8 1/2 3/4 1 11/4
mm 6 8 10 15 20 25 32
Dim.
(mm)
A 15.5 18.3 20.1 23.9 27.2 31.8 34.5
Size Inch 11/2 2 21/2 3 4 6
mm 40 50 65 80 100 150
Dim.
(mm)
A 36.9 39.7 46 49 64.5 71.5
